RockJock Narrow Forged 2" Johnny Joint

RockJock's narrow forged Johnny Joints® for fabricators and suspension system builders offer 40 degrees of unrestricted movement in any direction as compared to 22 degrees on a common heim joint! Johnny Joint® rod ends offer cushioning that a heim joint cannot provide via high-density urethane bushing that encases the inner ball. The heat treated center balls are cross-drilled for thru-bolt lubrication and the joint internals are retained with 2 heavy duty, heat treated side washers and a snap ring. This specific joint is a 2" diameter, fitted with a zerk fitting for greasing, 2 1/4" of 7/8"-14 right hand threads on the shank, and a 1.600" mounting width ball with a .562" thru bolt hole. Finished in gold zinc plating.

Used in all WCFAB Traction Bar Kits.
