Monster-Ram improves airflow from the intercooler. Flows 936 cfm (71.5 lbs/min) Banks High-Flow Heater and Billet Intake Plate compared to Stock's 421 cfm (32.16 lbs/min). Flows 520 cfm (39.72 lbs/min), with the stock heater plate.
Monster-Ram raises boost without increasing backpressure at the turbine. The result is a more responsive, power-efficient engine that offers even more headroom than stock for higher horsepower applications.
Add High-Flow Heater and Billet Intake Plate for max airflow
Although the Monster-Ram dramatically increases airflow using the stock heater plate, upgrading to Banks High-Flow Heater and Billet Intake Plate improves the performance 5x. The High-Flow Heater allows for the removal of the restrictive stock heater grid plate. The new vertical coil-style heater provides the same functionality for cold starts as the stock grid heater but without obstructing airflow. Replacing the restrictive stock grid heater plate with the Banks High-Flow Intake Plate removes all obstructions and turbulence in the airflow path.
How it was designed
Utilizing the latest in CFD (computational fluid-dynamics), tested on the flow bench, the dyno, and on-road, Monster-Ram is a beast that only Banks could have unleashed. A direct-replacement aluminum casting, Monster-Ram is instant power, performance, and acceleration gratification. The factory inlet elbow is cramped and angular in order to accommodate the path of the stock No. 1 fuel line. Banks Engineers designed a new No. 1 fuel line, allowing the Monster-Ram to flow more air without obstruction.
Expandable
With four 1/8” NPT ports, perfect for temperature and pressure sensors, the sky's the limit for data acquisition and expandability.
Billet Intake Plate Option
Banks’ High-Flow Heater and Billet Intake Plate complete the perfect system. The High-Flow Heater allows for the removal of the restrictive stock heater grid plate. The new vertical coil-style heater provides the same functionality for cold starts as the stock grid heater but without obstructing airflow. Replacing the restrictive stock grid heater plate with the Banks High-Flow Intake Plate removes all obstructions and turbulence in the airflow path.
Overview
Emissions Compliant: D-161-143(2013-18 50-State / 2007-12 49-State, CA in process)
