S364.5 SXE with 73MM Turbine and 3-inch V-Band Outlet (64.5mm/73mm)

Wehrli Custom Fabrication
Additional Images
Shipping: This Product Cannot Ship to the State of California
(0) Reviews: Write first review
WCF100181
- S300SX-E 64.5mm Compressor Wheel with 73mm Turbine
- 3” V-Band Outlet
- 360 degree thrust bearing
- Integrated speed sensor port
- Forged milled (FMW) compressor wheel
- Comp. Wheel Inducer Dia. (mm) 64.47
- Comp. Wheel Outer Dia. (mm) 87.37
- Pre-machined boost port
- Optimized compressor stage aerodynamics
- Rated for 450-825 HP
Availability: Raw in stock and ships in 3-5 business days. 10-15 business day lead time on powder coating.
Select Options & Add to Cart
NOTE: This product has the following shipping restriction(s):
  • This product cannot be shipped to California
Pricing: $1149.00

As low as $104/mo with . Check your purchasing power

*Select Powder Coating Reset

Select your Color. Color samples can be seen on the "Powder Coat Colors" page of the main menu.

*Select S300 Exhaust Housing Reset

*Select T4 Turbo Heat Blanket Reset

*Select T4 Exhaust Housing Finish Reset

*Select Mating Flange & Clamp Reset

Your Selected Options

Please select all required options.

Your Total Price

NOTE: This product has the following shipping restriction(s):
  • This product cannot be shipped to California
$1149.00
Qty:
NOTE: This product has the following shipping restriction(s):
  • This product cannot be shipped to California

California Residents: Prop 65 Warning

WARNING: Cancer and Reproductive Harm

Visit: www.p65warnings.ca.gov

Description

Borg Warner S364.5 SXE Turbo with 73mm Turbine. Compressor cover modified by WCFab to replace the standard 2.75" Hose Outlet with a 3" V-Band Outlet. Originally created for use with our 2nd Gen Swap kits for the 5.9 Cummins, these turbos can also be used for any application requiring a v-band outlet connection. Super-Core (center section and compressor cover) only, exhaust turbine housing sold separately. All turbine housing mounting hardware, clamp plates and cap screws included with Super-Core.

*Not included with turbo assemblies: Speed sensor, Drain port fitting*
